Master FC400 is a frequency converter suitable for airport, military, and naval applications requiring a consistent 400 Hz output from either a 50 Hz or 60 Hz input. Adjustable 3-phase output voltage (200-215V).
Galvanic Isolation
Fully integrated output transformer guarantees the separation of the load from mains disturbances under all conditions. Takes incoming power at 50 or 60 Hz and converts it into a consistent and stable 400 Hz output.
Easy Installation And Maintenance
Master FC400 has a compact footprint, for example, a 125 kVA model requires just 0.86 m² floor space. All key components are easily accessed from the front of the UPS. With no need for side or rear clearance, you can install the UPS right up against the wall or in the corner.
Choice of 5 power ratings
Flexible frequency converter (50 or 60 Hz input; 400 Hz output)
Ideal solution for airports, military, and naval applications
Front to top ventilation enables space-saving back-to-back install
Compact footprint helps optimise your floor space
Ensures galvanic isolation
Can also be used as a standard UPS with battery backup
| Models | MFC 125 |
|---|---|
| INPUT | |
| Voltage | 380 / 400 / 415 V three-phase |
| Voltage tolerance | 400 V ±20% @ full load |
| Frequency tolerance | 45 ÷ 65 Hz |
| Current distorsion | <5% C (HC Version) |
| Soft start | 0 - 100% in 120 sec. configurable |
| OUTPUT and INVERTER OUTPUT | |
| Rated power | 125000 VA |
| Active power | 100000 W |
| Number phases | 3 |
| Crest factor (Ipeak/Irms) | 3 : 1 |
| Waveform | sinusoidal |
| Static stability | ±1% |
| Dynamic stability | ±5% |
| Frequency | 400 Hz |
| Voltage distortion with non-linear load | <4% |
| Voltage distortion with linear load | <3% |
| Overload | 110% for 60 min.; 125% for 10 min.; 150% for 1 min. |
| ENVIRONMENTAL | |
| Color | Light gray RAL 7035 |
| Communication | Double RS232 + remote contacts + 2 slots for communications interface |
| Protection rating | IP20 |
| AC/AC efficiency | up to 92% |
| Noise (at 1 m) | 72 dBA |
| Operating temperature | 0 °C - 40 °C (50°C @ 75% load) |
| Relative humidity | 5-95% non-condensing |
| Standards | European directives: L V 2014/35/EU low voltage; EMC 2014/30/EU electromagnetic compatibility -- Directive and Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2; RoHS compliant -- Classification in accordance with IEC 62040-3 VFI - SS - 111 |
| DATA | |
| Weight | 590 kg |
| Dimensions (h w d) | 1900 x 800 x 800 mm |
Master FC400 is a frequency converter that takes incoming power at 50 or 60 Hz and converts it into a consistent and stable 400 Hz output. Available in 5 different power ratings (30-60-80-100-125 kVA).
Provides proven protection across a range of transportation settings, including airports, radar and flight-control systems, naval or military applications, and for powering test benches. Also available as a UPS with battery backup.
Fully integrated output transformer guarantees the separation of the load from mains disturbances under all conditions.
Master FC400 has a compact footprint, for example, a 125 kVA model requires just 0.86 m² floor space.
All key components are easily accessed from the front of the UPS. With no need for side or rear clearance, you can install the UPS right up against the wall or in the corner.
