Reliable power for a sustainable world
Master Industrial (MIM) is designed to withstand the vibrations, mechanical stresses and dust that are commonly found in harsh industrial environments such as manufacturing, petrochemical, and power plants.
Complete Galvanic Isolation
Input and inverter isolation transformers guarantee separation between the load and the batteries. Battery is sized to deliver 220Vdc voltage, the standard for industrial environments.
Fully Redundant Fans
Redundant ventilation system at up to 100% load ensures UPS runs at safe operating temperatures even if there’s an issue with any of the fans. Each fan is monitored individually and will alarm in the event of failure, ensuring swift replacement.
Choice of 4 power ratings
Battery designed to deliver 220Vdc voltage
Specially designed to handle harsh industrial environments
Ideal for applications such as manufacturing, petrochemicals, and electrical distribution
94% operating efficiency (ONLINE mode) reduces energy waste
Handles high short circuit currents, so ideal for loads with high current peaks
Redundant fans even at 100% load
Input and output transformers ensure galvanic isolation
| Models | MIM 30 |
|---|---|
| INPUT | |
| Rated power | 30000 VA |
| Voltage | 400 V three-phase |
| Voltage tolerance | 400 V ±20% @full load |
| Frequency | 50 or 60 Hz with autorange |
| Frequency tolerance | 45 - 65 Hz |
| Power factor | >0.93 |
| Current distorsion | <6% |
| Soft start | 0-100% in 120" configurable |
| BY PASS | |
| Rated voltage | 400 Vac three-phase selectable 380 and 415 |
| Voltage tolerance | ±15% (selectable from ±10% to ± 25% from front panel) |
| Rated frequency | 50 or 60 Hz (autorange) |
| Frequency tolerance | ± 2% (selectable from ± 1% to ± 5% from front panel) |
| Rated current | 145 A |
| Number phases | 3 |
| Back-feed protection | yes |
| OUTPUT and INVERTER OUTPUT | |
| Rated power | 30000 VA |
| Active power | 24000 W |
| Number phases | 1 |
| Crest factor (Ipeak/Irms) | 3 : 1 |
| Waveform | Sinewave |
| Static stability | ±1% |
| Dynamic stability | ±5% |
| Frequency | 50 or 60 (configurable) |
| Voltage distortion with non-linear load | <3% |
| Voltage distortion with linear load | 1% (typical) 2% (max) |
| Frequency stability | ±2 (configurable from ±1% to ±5% from control panel) |
| Inverter efficiency at rated load | 91% % |
| Overload | 110% for 60 min.; 125% for 10 min.; 150% for 1 min. |
| RECTIFIER OUTPUT | |
| Ripple | <1% |
| BATTERIES | |
| Type | Maintenance-free sealed lead-acid |
| Maximum recharge current | 0.2xC10 |
| ENVIRONMENTAL | |
| Color | Light grey RAL 7035 |
| Remote controls | ESD and bypass |
| Protection rating | IP20 |
| Cooling (type) | redundant fans (front-top) |
| AC/AC efficiency | 92.5% |
| Noise (at 1 m) | 68-70 dBA |
| Remote signals | dry contacts |
| Operating temperature | 0 ÷ 40 °C |
| Relative humidity | 5-95% non-condensing |
| Standards | European directives: L V 2014/35/EU low voltage; EMC 2014/30/EU electromagnetic compatibility -- Directive and Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2; RoHS compliant -- Classification in accordance with IEC 62040-3 VFI - SS - 111 |
| DATA | |
| Weight | 640 kg |
| Dimensions (h w d) | 1900x800x800 mm |
Master Industrial is our specialist uninterruptible power supply designed to provide maximum protection and power quality in settings such as power stations, manufacturing factories, and petrochemical processing plants.
It has a high short circuit current, which makes it ideal for loads that draw a high current during switch-on or normal operation, such as motors and industrial machinery.
Specifically designed to cope with vibrations, dust, and mechanical stresses that would pose problems and increase the likelihood of failure for standard UPS systems.
Input and inverter isolation transformers guarantee separation between the load and the batteries. Battery is sized to deliver 220Vdc voltage, the standard for industrial environments.
Redundant ventilation system ensures UPS runs at safe operating temperatures even if there’s an issue with any of the fans. In addition, each fan is monitored individually and will alarm in the event of failure, ensuring swift replacement.
